Toyota Highlander Service Manual: Transfer

Drive shaft / propeller shaft / axle

Brake

More about Toyota Highlander:

Propeller W/Center bearing shaft Propeller w/center bearing shaft
OVERHAUL HINT: COMPONENTS:SEE PAGE 30-4 1. REMOVE EXHAUST PIPE ASSY 2. REMOVE PROPELLER W/CENTER BEARING SHAFT ASSY (a) Depress the brake pedal and hold it. (b) Using a hexagon wrench (6 mm), loosen the cross groove joint set bolts 1/2 turn. HINT: Put a piece of shop rag or equivalent i ...
