Voltage inverter ASSY
REPLACEMENT
HINT:
COMPONENTS: See page 67-2
Installation is in the reverse order of removal.
1. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSY CENTER (SEE PAGE 71-10 )
2. REMOVE FRONT SEAT ARMREST ASSY CENTER (SEE PAGE 71-10 )
3. REMOVE CONSOLE BOX ASSY (SEE PAGE 71-10 )
4. REMOVE VOLTAGE ...
