Toyota Highlander Service Manual: Components

Generator ASSY (2AZ-FE)

...

Replacement

1. REMOVE V BELT (See page 14-5 ) 2. REMOVE GENERATOR ASSY (a) Remove the bolt, and disconnect the wire clip on the wire connectors from the generator. (b) Disconnect the wire clamp from the w ...

More about Toyota Highlander:

Overhaul
HINT: Use the same procedures for the RH side and LH side. The procedures listed below are for the LH side. Installation is in the reverse order of removal. 1. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSY LH (SEE PAGE 76-2 ) 2. REMOVE FOG LAMP PROTECTOR LH (a) Disengage the 2 claws, a ...
