Warning
In the event of sudden braking or sudden swerving, an accident may occur due to an occupant being struck by an open lid or the items stored inside. |
Glove boxAccelerator pedal rod ASSY (3MZ-FE)
REPLACEMENT
1. REMOVE ACCELERATOR PEDAL ROD ASSY
(a) Disconnect the accelerator pedal position sensor connector.
(b) Remove the 2 bolts and pedal rod.
2. INSTALL ACCELERATOR PEDAL ROD ASSY
(a) Install the pedal rod with the 2 bolts.
Torque: 4.9 NVm (50 kgfVcm, 43 in.Vlbf)
(b) Connect th ...
