Toyota Highlander Owners Manual: Positioning a floor jack

Toyota Highlander Owners Manual / Maintenance and care / Do-it-yourself maintenance / Positioning a floor jack

When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely.

When raising your vehicle with a floor jack, position the jack correctly.

Improper placement may damage your vehicle or cause injury.

Front

Toyota Highlander. Front

Rear

Toyota Highlander. Rear
